Dama 5.5T Premier 4 Post Lift HDM55F4
Dama Premier build quality in a 5.5 tonne service and wheel alignment 4 post lift.
The Dama HDM5.5F4 comes from the Premier range, with heavier construction and extra safety features. It has 5190mm platforms, built in lockable slip plates, removable plates for front turnplates, air locking and a rope slack safety system, on single or 3 phase power. Backed by a 2 year parts and labour warranty.
Who it's for
- Busy service and MOT preparation workshops
- Tyre and alignment centres
- Bodyshops needing a heavy duty 4 post
Why you'll love it
- Run servicing and wheel alignment on one premium lift
- Lift heavier cars, EVs and vans with 5.5 tonne capacity
- Raise in under 50 seconds
What sets it apart
- Pneumatic locking with steel rope security switch
- Electromagnetic lowering valve and top limit switch
- One moving platform for different track widths
- Single or 3 phase versions
How you'll use it
Drive up the long run on ramps, set the wheels on the turnplates and slip plates and raise the lift. The air locks hold it level for alignment, and the moving platform adjusts to the vehicle's track.
Manufacturer warranty
Backed by Dama's 24 month manufacturer warranty, with UK support from our team on 0116 4810180.
Key features
- Electro hydraulic
- Electromagnetic lowering valve
- Pneumatic locking system
- Steel rope security switch
- Top limit switch
- Built in lockable slip plates
- Removable plates for front turnplates
- Long run on ramps
Technical specification
| Maximum lifting capacity | 5500kg |
|---|---|
| Platform length | 5190mm |
| Lifting time | under 50 seconds |
| Lowering time | under 60 seconds |
| Lift weight | 1690kg |
| Air supply | 6 to 8 bar |
| Power supply | 400V 3 phase 2.2kW or 230V 1 phase 2.2kW |
| Warranty | 24 months parts and labour |
