Majorlift 4T Manual Jacking Beam HPJ4

Majorlift 4T Manual Jacking Beam

Some vehicles demand more. The HPJ4 delivers serious 4 tonne lifting capacity for workshops that regularly handle larger commercial vehicles - built to withstand the structural demands of heavy-duty operation without compromise. At 155kg, this is a beam engineered for environments where rigidity and rated capacity are non-negotiable, and where DVSA compliance is the baseline, not the ceiling.

Hand pump operation keeps it reliable in any workshop without dependency on compressed air. The height-adjustable mounting bracket fits any existing lift without modification, and the three-position mechanical lock engages automatically on every lift. Extending to 1605mm and retracting to 864mm, it handles a wide range of vehicle widths while storing efficiently in the bay. Supplied with extension sets and rubber cushions.

Features

• Exceeds DVSA Minimum Requirements - fully compliant with DVSA special notice 04/25 for MOT bay authorisation
• 4 Tonne Rated Capacity - built for heavy commercial vehicles where lower-capacity beams are not sufficient
• Manual Hand Pump Operation - no air supply required, delivering consistent, reliable performance in any workshop environment
• 1605mm Extension / 864mm Retracted - covers a wide range of commercial vehicle widths with compact storage when not in use
• Low Jacking Position - accommodates low-floored vehicles including sports cars without the need for additional adapters
• Three-Position Mechanical Lock - engages automatically to create a safe working platform during wheel overhauls, minimising operator error risk
• Full Safety Compliance - hose burst valve, pressure release valve to prevent overloading, and finger guard compliant with European Machinery Directive (CE marked)
• Height-Adjustable Mounting Bracket - fits any lift without modification, simplifying installation across mixed-brand lift fleets
• Flexible Extension Beam - eliminates the need for multiple tools across different vehicle widths, reducing equipment overhead
• Roller Support Arms Included - supplied with roller flat or roller hook support arms; specialist arms available on request

Specifications

• Part Number: HPJ4
• Rated Capacity: 4T
• Operation: Manual (Hand Pump)
• A - Width When Extended: 1605mm
• B - Width When Retracted: 864mm
• C - Min. Width Over Support Arms: 830mm
• D - Max. Width Over Support Arms: 1300mm
• E - Closed Height: 261mm
• F - Total Lift: 205mm
• Weight with Top Beam: 155kg
• MOT Approval: N/A
